Harden Steel Mold Bearings , Self Lubricating Bearing Long Operating Life

Harden Steel Mold Bearings , Self Lubricating Bearing Long Operating Life

Harden Steel Mold Bearings , Self Lubricating Bearing Long Operating Life
Harden Steel Mold Bearings , Self Lubricating Bearing Long Operating Life Harden Steel Mold Bearings , Self Lubricating Bearing Long Operating Life

Large Image :  Harden Steel Mold Bearings , Self Lubricating Bearing Long Operating Life Get Best Price

Product Details:

Place of Origin: CHINA
Brand Name: WHB
Certification: ISO3547/ISO9001
Model Number: JDB

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: Negotiation
Packaging Details: Export wooden case, wood pallet.
Delivery Time: 15-20 work days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 450000pcs per month
Detailed Product Description
Keywords: High Load Harden Steel Material: Steel
Apply For: Engineering Machinery Size: Customizable
Feature: High Hardness Advantage: High Temperature Resistance
High Light:

mold bearings

,

sintered bronze bushing

High Load Harden Steel Mold Bushings Self-Lubricating With Long Operating Life​



1. Product Description

    High Load Harden Steel Mold Bushings Self-Lubricating With Long Operating Life is produced by carbon steel with oil groove,the initial grease given can be deposited the mass lubrication for long time working.The work surface can been sprayed a special solid lubricant,this solid lubricant can be transfer to the mating material during the operation and forming a solid lubrication film between the bearing and shaft which make the bearing material have high load capacity with lower friction and excellent wear resisance.



2. Specification



Basic material Gcr15 Dynanic load 250N/mm²
Base hardness HRC58~60 Friction Coef <0.17
Temperature Max 350℃ Speed limit

dry 0.1m/s oil 15m/s





3. Application

     High Load Harden Steel Mold Bushings Self-Lubricating With Long Operating Life are widely applied in moulds,hoisting machinery,engineering machinery etc.



4. Advantages

     It's good performance of high crash strength can be shown in supporting position of hoisting machine, the solid lubricant have been embedded instead of covering on surface which can provide the solid lubricant for much long time during the operation even without any oil given this material provides a maintenance-free design solution,particularly for high load,intermittent of oscillating motion with lower speed and excellent wear resistance required.
